JP Turbo Universal B480X WITH 3” Ball Bearing Supercore

Product Number: 5010150004

US$1,296.00

{{shoplineProductReview.avg_score}} {{'product.product_review.stars' | translate}} | {{shoplineProductReview.total}} {{'product.product_review.reviews' | translate}}

{{amazonProductReview.avg_rating}} {{'product.product_review.stars' | translate}} | {{amazonProductReview.total_comment_count}} {{'product.product_review.reviews' | translate}}

The maximum quantity per submit is 99999

This quantity is invalid, please enter a valid quantity.

Sold Out

Please message the shop owner for order details.

Description

Shipping & Payment

Description

Turbine Kits

Model	Supercore	A/R	Inlet	outlet	Turbine Kits	Purchase link
B480X	5010150004	0.61	T25	V-BAND	5070050001	■
		0.73	T25	V-BAND	5070050002	■
		0.61	T3	V-BAND	5070050003	■
		0.73	T3	V-BAND	5070050004	■
		0.61	V-BAND	V-BAND	5070050005	■

※ Buy Together and Save More

Overview

The B480X supercore is a universal turbocharger. The target horsepower is to correspond to a maximum horsepower of 480HP. With the patented double ceramic ball bearing, the turbocharger can prolong the service life and spool up faster. The water-cooled CHRA keeps the temperature as low as possible to ensure the lifespan of the product during intense driving. The turbos are made of Inconel, a superalloy that maintains its strength over prolonged exposure to high exhaust temperatures. Turbo exhaust housings are available in a variety of options, as well as various A/R and flange configurations.

Application for

1.4-2.5 GASOLINE ENGINE
2.8-5.0 DIESEL ENGINE

Dyno Testing

※The values may be different due to the different modifications and setting on each vehicle.

Features

Patented JP Turbo dual ceramic ball bearing
The low friction allows the bearing to work at much lower required force and gives a boost at earlier RPM. The ceramic ball is made of Si3N4 high-precision fine ground ceramic ball. The spherical surface is in a perfect mirror state. With the match of the high-temperature, wear-resistant, shock-resistant and lightweight retainer cage, our bearings give an earlier boost than other ball bearings!

This upgraded high-flow turbine wheel comes with Inconel alloy. It consists of metal nickel, able to withstand higher temperature and pressure. As to the blade design, it offers much higher efficiency in terms of airflow, smoother exhaust and backpressure reduction. In return, we have much better wheel performance.
Enlarge Inconel high-low turbine wheel
The upgraded aero grade aluminum billet compressor wheel allows higher intake air volume and improves air inlet efficiency.
Enlarge Aero Grade Aluminum Billet Wheel.

Balanced by Schenck balancing machine
Precise balancing is a crucial process in the production of JP Turbo. A well-balanced turbocharger is vital for ensuring excellent performance and reliability, as well as minimizing the noise generated during high-speed operation. To achieve the best balance, we have strict operating standards in place. We start by performing low-speed dynamic balancing using a high-precision single-piece balancing machine. Then, we assemble the CHRA parts with great care before subjecting them to high-speed dynamic balancing. Our state-of-the-art high-speed dynamic balancing machine can reach a maximum speed of 250,000 RPM, surpassing OEM standards. We assign a unique serial number to each turbo and keep the balance test results in our database for future reference. The Schenck balancing machine ensures that the turbos are balanced to perfection.
